Gigabyte B550 EAGLE WIFI6 ATX AM4 Motherboard
49 people are viewing this product right now
🔥 3 sold in last 3 hours
🛍️ 3 customer have this in their cart
🛍️ 3 customer have this in their cart
- AMD Socket AM4 : Supports AMD Ryzen™ 5000 / 4000 / 3000 Series Processors
- Digital twin 10+3+1 phases VRM solution
- Dual Channel DDR4 : 4*DIMMs with AMD EXPO™Memory Module Support
- EZ-Latch : PCIe slots with Quick Release Design
Original price was: ₹22,550.00.₹14,715.00Current price is: ₹14,715.00. (Inclusive of GST)
Shipping calculated at checkout.
Estimated delivery:4 days
Gigabyte B550 EAGLE WIFI6 ATX AM4 Motherboard
Feature
- AMD Socket AM4 : Supports AMD Ryzen™ 5000 / 4000 / 3000 Series Processors
- Digital twin 10+3+1 phases VRM solution
- Dual Channel DDR4 : 4*DIMMs with AMD EXPO™Memory Module Support
- EZ-Latch : PCIe slots with Quick Release Design
- Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
- Ultra-Fast Storage : 2*M.2 slots, including PCIe 4.0 x1
- Efficient Thermal : VRM Thermal Armor Advanced
- Fast Networking : GbE LAN & Wi-Fi 6
- Extended Connectivity : HDMI, Displayport
- PCIe UD Slot : PCIe 4.0 x16 slots with 10X strength for graphics card & Better Heat dissipation effect
Memory
Infinite Memory Performance
Gigabyte EAGLE motherboards boost DDR4 memory performance and offer top-notch compatibility using various advanced methods.
Sturdy VRM Design
Steady Power
Eagle Series with steady power keeps your AI operation smooth.
Digital Twin VRM Design
Delivers consistent, high-powered performance to elevate your overclocking to the next level.
10 VCORE Phases Ppak
Unlock the full power of your multi-core CPU for unmatched performance.
* 5+5 phases parallel power design
3 SOC Phase Ppak
Optimized for integrated GPU performance and memory management within the CPU.
1DDR Phases Ppak
Cooling
Comprehensive Thermal
Advanced full-metal thermal design and durable heatsinks to keep your system cool and efficient.
“Stay Cool, Game On”
High-coverage MOSFETs with integrated molded heatsinks
Larger surface area for enhanced heat dissipation
- More Bigger surface area of traditional coolers, this advanced design significantly boosts MOSFET cooling performance
5 W/mK thermal pad for efficient thermal conductivity
- High-performance thermal pad
- Keeps your system cool and running at peak efficiency
Easy & Friendly
Hassle-free Assembly
Our cutting-edge motherboard is designed for the ultimate DIY experience. Creating your own PC becomes a delightful and smooth process.
Q-FLASH Auto Scan
The new Auto Scan function featues when using USB flashdrive during Q-Flash, the BIOS file will be auto scanned instead of searching manually.
| Category | Details |
|---|---|
| CPU | AMD Socket AM4, support for: |
| – AMD Ryzen™ 5000 G-Series Processors | |
| – AMD Ryzen™ 5000 Series Processors | |
| – AMD Ryzen™ 4000 G-Series Processors | |
| – AMD Ryzen™ 3000 G-Series Processors | |
| – AMD Ryzen™ 3000 Series Processors | |
| (Go to GIGABYTE’s website for the latest CPU support list.) | |
| Chipset | AMD B550 |
| Memory | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory |
| Support for DDR4 3200/2933/2667/2400/2133 MT/s memory modules | |
| Dual channel memory architecture | |
| Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules | |
| Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
| Support for Extreme Memory Profile (XMP) memory modules | |
| (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.) | |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics support: |
| – 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz | |
| * Support for HDMI 2.1 version, HDCP 2.3, and HDR. | |
| ** Support for native HDMI 2.1 TMDS compatible ports. | |
| (Graphics specifications may vary depending on CPU support.) | |
| Maximum shared memory of 16 GB | |
| Audio | Realtek® Audio CODEC |
| High Definition Audio | |
| 2/4/5.1/7.1-channel | |
| * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. | |
| LAN | Realtek® GbE LAN chip (1 Gbps/100 Gbps/10 Mbps) |
| Wireless Communication | Realtek® Wi-Fi 6 RTL8851BE |
| – WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands | |
| – BLUETOOTH 5.3 | |
| – Support for 11ax 80MHz wireless standard | |
| (Actual data rate may vary depending on environment and equipment.) | |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
| – AMD Ryzen™ 5000/3000 Series Processors support PCIe 4.0 x16 mode | |
| – AMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support PCIe 3.0×16 mode | |
| * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
| Chipset: | |
| – 4 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1, PCIEX1_2, PCIEX1_3, PCIEX1_4) | |
| Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs: |
| – AMD Ryzen™ 5000/3000 Series Processors support SATA and PCIe 4.0×4/x2 SSDs | |
| – AMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support SATA and PCIe 3.0 x4/x2 SSDs | |
| 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 3.0 x4/x2 SSDs | |
| 4 x SATA 6Gb/s connectors | |
| RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices | |
| RAID 0, RAID 1, and RAID 10 support for SATA storage devices | |
| USB | CPU: |
| – AMD Ryzen™ 5000/3000 Series Processors support one USB 3.2 Gen 2 Type-A port (red) on the back panel | |
| – AMD Ryzen™ 5000 G/4000 G/3000 G-Series Processors support one USB 3.2 Gen 1 port (red) on the back panel | |
| – 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support | |
| – 2 x USB 3.2 Gen 1 ports on the back panel | |
| Chipset: | |
| – 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header | |
| – 2 x USB 3.2 Gen 1 ports available through the internal USB header | |
| – 4 x USB 2.0/1.1 ports available through the internal USB headers | |
| Chipset+USB 2.0 Hub: | |
| – 4 x USB 2.0/1.1 ports on the back panel | |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector |
| 1 x 8-pin ATX 12V power connector | |
| 1 x CPU fan header | |
| 1 x CPU fan/water cooling pump header | |
| 3 x system fan headers | |
| 2 x addressable LED strip headers | |
| 2 x RGB LED strip headers | |
| 1 x CPU cooler LED strip/RGB LED strip header | |
| 2 x M.2 Socket 3 connectors | |
| 4 x SATA 6Gb/s connectors | |
| 1 x front panel header | |
| 1 x front panel audio header | |
| 1 x USB Type-C® header, with USB 3.2 Gen 1 support | |
| 1 x USB 3.2 Gen 1 header | |
| 2 x USB 2.0/1.1 headers | |
| 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) | |
| 1 x Clear CMOS jumper | |
| Back Panel Connectors | 4 x USB 2.0/1.1 ports |
| 2 x antenna connectors (1T1R) | |
| 1 x HDMI port (Note) | |
| 1 x USB 3.2 Gen 2 Type-A (Note)/USB 3.2 Gen 1 port (red) | |
| 1 x USB Type-C® port, with USB 3.2 Gen 1 support | |
| 1 x Q-Flash Plus button | |
| 1 x RJ-45 port | |
| 2 x USB 3.2 Gen 1 ports | |
| 3 x audio jacks | |
| (Note) Actual support may vary by CPU. | |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection |
| Temperature detection | |
| Fan speed detection | |
| Water cooling flow rate detection | |
| Fan fail warning | |
| Fan speed control | |
| * Whether the fan speed control function is supported will depend on the fan you install. | |
| BIOS | 1 x 128 Mbit flash |
| Use of licensed AMI UEFI BIOS | |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Unique Features | Support for APP Center |
| * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | |
| – @BIOS | |
| – EasyTune | |
| – RGB Fusion | |
| – Smart Backup | |
| – System Information Viewer | |
| Support for Q-Flash Plus | |
| Support for Q-Flash | |
| Bundled Software | Norton® Internet Security (OEM version) |
| LAN bandwidth management software | |
| Operating System | Support for Windows 11 64-bit |
| Support for Windows 10 64-bit | |
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm |
| Warranty | 3-year warranty |
