ZEBRONICS ZEB-H61M2 with PCIE M.2 / NVMe Slot (LGA 1155 Socket) Motherboard (Black)
Feature
Socket Type: The motherboard ZEBRONICS features an LGA 1155 socket, which is compatible with Intel Core 2nd and 3rd Gen processors. Chipset: It utilizes the Intel H61 Express Chipset, providing essential features for stable system performance.
Expansion Slots:
- PCI Express x16 Slot: For adding a dedicated graphics card.
- PCI Express x1 Slot: For other expansion cards.
Audio:
- The onboard audio solution uses the Realtek 662 audio codec.
- You’ll find three audio jacks for 6-channel high-definition audio.
On-Board Connectors:
- Front Panel Connector: Used for connecting power/reset buttons and LEDs.
- Speaker Connector: For system audio.
- Front Panel Audio Connector (2 x 5-pin): Connects front panel audio jacks.
- USB 2.0 Ports: Additional internal USB connectors.
- SATA Ports (SATAII): For connecting hard drives and optical drives.
- CPU Fan Connector (4-pin): For CPU cooling fans.
- SYS Fan Connector: For system fans.
- 24-pin ATX Power Connector: Supplies power to the motherboard.
- 4-pin ATX 12V Power Connector: Provides additional power to the CPU.
- 3-pin Clear CMOS Header: Used for resetting BIOS settings.
Memory Support:
- The ZEB-H61M2 has two DDR3 dual-channel slots for RAM.
- It supports DDR3 memory speeds of 1066/1333/1600MHz.
- The maximum RAM capacity is 16 GB.
LAN (Network):
- The motherboard supports Realtek 8106E 10/100 Mbps Ethernet for network connectivity.
- Back Panel Ports:
- PS/2 Mouse/Keyboard Port: For legacy peripherals.
- VGA Port: For connecting monitors.
- HDMI Port: For high-definition video output.
- Four USB 2.0 Ports: For connecting peripherals.
- LAN Port: For wired network connectivity.
- Three Audio Jacks: For audio output.
Specifications
| Supported CPU | Intel Pentium/Celeron/Core i3, i5, i7 Series Processors in LGA 1155 | |
| Chipset | Intel H61/H67 | |
| Memory Supported | 2nos DDR3 Dual channel RAM slots Memory up to 16GB Supports dual channel DDR3 1066/1333/1600MHz memory | |
| BIOS | AMI BIOS | |
| I/O Interface | 1 x HDMI port, 1 x VGA Port, 6 x USB 2.0 Port, 1 x RJ45 Port, 1 x 3-in-1 Audio | |
| Onboard Interface | 1 x 24 pin ATX Power Connector, 1 x 4 Pin ATX 12V Power Connector, 6 x USB 2.0 Ports, 1 x Front Audio Connector, 1 x Front Panel Connector, 1 x Speaker Connector, 2 x Fan Connectors, 3 x SATA II Ports, 1 x 3pin CMOS Header, m.2 Slot | |
| Integrated Sound | With 6-Channel HD Audio Codec onboard | |
| Integrated LAN | Supports Realtek 8106E 10/100 Mbps | |
| Expansion Slot | 1 x PCI Express 2.0 x16 size slot, 1 x PCI Express 2.0 x1 size slot | |
| Form Factor | Micro-ATX | |
| Country of Origin | People’s Republic of China |
| Weight | 1 kg |
|---|
